In the past, patients often needed to spend a lot of time processing and decoction before taking traditional Chinese medicine, and then took the bitter Chinese medicine. With the development of science and technology, the emergence of tablet presses has changed the processing and taking forms of traditional Chinese medicine. Among them, the rotary tablet press is a new type of traditional Chinese medicine tablet press equipment, suitable for pharmaceutical, food, chemical, light industry and other industries. It can be seen in many places. Just grind the Chinese medicine into powder and put it into the machine, and it can be made into pills one by one like Western medicine. The operation is very simple. The advantages of the rotary tablet press are highlighted. It is understood that the traditional Chinese medicine tablet press is a basic equipment used to press various granular raw materials into round tablets and special-shaped tablets, and is suitable for mass production. Since the rotary tablet press is based on the basic principle of a single-punch tablet press, and at the same time addresses the shortcoming of being unable to discharge air instantaneously, it changes the instantaneous pressure to a continuous and gradually increasing or decreasing pressure, thereby ensuring the quality of the tablets. At the same time, medicinal powder
Read More
Among metal materials, austenitic stainless steel is the most widely used material for pharmaceutical equipment products. Common varieties include 316L (00Cr17Ni14Mo2), 316 (0Cr17Ni12Mo2), 304L (00Cr19Ni11), 304 (0Cr19Ni9) and 1Cr18Ni9Ti (commonly known as 18-8). Their common characteristics are corrosion resistance and good heat resistance. The commonality of these austenitic stainless steels is corrosion resistance, and their 'corrosion resistance' is relative, which refers to the characteristics of high chemical stability in certain external conditions and certain corrosive media. However, when this kind of austenitic stainless steel is used in certain media, it will produce intergranular corrosion, pitting corrosion and other types of corrosion. Especially in Cl-containing media, corrosion is very easy to occur. Ultra-low carbon or low carbon methods are usually used to solve the problem (that is, 316L or 304L). However, ultra-low
Read More
Taizhou Tiantai Tablet Press Installation Instructions 1. This machine is packaged as a whole. After unpacking, move it to a suitable place for use. It can be used after it is leveled. If the position is fixed, anchor screws can be installed. 2. For electrical circuits and devices, attention should be paid to the voltage. If the user does not propose it, it will be stipulated as 380 volts. When wiring, the direction of rotation of the motor should be paid attention to. It must be consistent with the direction of the arrow on the machine and must not be reversed. To ensure electrical safety, an effective ground wire must be installed. 3. This machine should be used indoors in a dry, clean and well-lit environment. Taizhou Tiantai Tablet Press Maintenance Instructions 1. Check the machine parts regularly, 1-2 times a month. The inspection items are whether the worm gear, worm, bearing, pressure wheel, crankshaft, upper and lower guide rails and other movable parts rotate freely and are worn. Any defects found should be repaired and used in time. 2. After a single use or when work is stopped, the remaining powder should be taken out and the residual powder on the machine name should be brushed away. If it is not used for a long time, all the punch dies must be removed and the machine must be removed.
Read More
The bearings, worms and worm gears in the machine lubrication reduction gearbox of Taizhou Tiantai coating machine adopt full splash lubrication. The uppermost bearing is lubricated by an oil cup, which should be refilled regularly. The oil of the reducer is changed every six months, using HL20 in winter, HL30 in summer, and ZG-2 calcium-based grease for rolling bearings. Installation and debugging 1. After the machine is in place, it must be placed stably and fixed with anchor bolts. 2. Open the oil filling cap and add lubricating oil to the reduction gearbox to the oil mark. 3. After the power is turned on, pay attention to the phase sequence and make the icing pan rotate clockwise. 4. During the test run, you should pay attention to whether there is any noise from the machine so that you can stop it for inspection in time. 5. The inclination angle of the sugar-coating pan is related to the loading capacity and material performance. When the inclination angle of the sugar-coating pan is 30°, the production efficiency and quality are both good. Operating procedures 1. Before operation, carefully check whether the fasteners of each part of the machine are loose. 2. Clean the inside and outside of the icing machine pan. 3. Start the main motor and let the machine idle for 2 minutes to
Read More
1. The working principle of Taizhou Tiantai coating machine is to coat the chips evenly with coating crystals on their surface as soon as possible and achieve the purpose of polishing. The chips in the pot must be sprayed with syrup in batches, and then the pot body should be rotated clockwise to roll, rub and grind the sugar-coated tablets in the pot to make the sugar coating uniform. At the same time, hot air is passed into the pot to quickly remove the moisture on the sugar-coated surface of the tablets, and finally obtain evenly wrapped and smooth sugar-coated tablets. The coating machine is a commonly used equipment in the sugar-coating process. It rotates at a stable linear speed of the pot to make the tablets form a parabolic curve in the pot, achieving the process requirements of uniform thickness of the sugar-coating layer, bright color, and no pitting. 2. Machine features (1) The machine is equipped with an eccentric wheel, which allows the user to adjust the inclination angle of the sugar-coating pan according to the characteristics of the tablets. (2) Using worm gear as the terminal output of motion, the operation is smooth. (3) The hot air assembly device adopts resistance wire heating and has separate high and low temperature controls for easy control. 3. Coating machine machine
